Automatic Print & Apply

A high-performance print and apply label system designed for seamless integration into high-end production processes with faster speeds and extensive I/O points can significantly enhance automation capabilities.

Product Details

The LabelMill LM3612 is a high-speed print-and-apply label machine designed for seamless integration into diverse production lines. Supporting thermal transfer and direct thermal printing, it efficiently labels various product types at speeds up to 16 inches per second. With features like a 12-inch label spool, user-friendly software, and optional upgrades, it’s ideal for industries ranging from manufacturing to food and beverage.

Benefits

The LabelMill LM3612 enhances efficiency with high-speed labeling of up to 90 products per minute, reducing manual labor and increasing productivity. Its versatility supports various product types and industries, from food and beverage to pharmaceuticals, ensuring adaptability to different production needs. The durable industrial design, user-friendly software, and optional upgrades, such as zero-downtime labelers and custom applicator modules, provide reliable performance and seamless integration into existing workflows. This label applicator helps streamline operations, improve labeling accuracy, and minimize downtime.

Specs

Labeling Speed/Rate: Up to 16” per second and, depending on label and product size, approximately 10 to 90 per minute
Print Method: Thermal transfer and direct thermal
Interface: Centronics parallel, RS-232c Serial, Ethernet, Wireless, USB
Bar Codes: UPC-A, UPC-E, EAN-8, EAN-13, CODE 3912/5, CODE 128, CODABAR, MSI, 2/5, CODE 93, UPC Bookland, Matrix 2/5, POSTNET, UCC/EAN 128, PDF-417, Maxicode, Data Matrix
Bar Code Ratios: 1:2, 1:3, 5:2
Interface Sensors: Product sensor-photo eye/limit switch/PLC input Auxiliary output with connector standard
Electrical:115 VAC/60Hz – 250 W idle, 600 running
Human Readable Fonts: 12 proportional and mono-spaced fonts including OCR-A and OCR-B representations and an outline font. American and European characters, uppercase and lower case with descenders (code table 850)
Air Requirements: 80 psi/3 cfm when equipped with tamp, flag, blow, swing, or corner wrap
Environment: Operating 50-95° F (10-35° C) 15-85% RH, non-condensing
Label Size: Minimum 1” wide x 1/2” long
General Size: 25”W x 22”D x 21”H
Weight: 61 lbs. with u-arm
Label Roll Capacity: 12” maximum outside diameter wound on a 3” I.D. core. Die-cut waste removed with minimum of 1/8” separations between labels in running direction

Use Cases

• Mid to high-volume product applications
• Print & apply labels to conveyed or robotically presented products

Print & Apply:

• Barcodes
• Expiration & Best By Dates
• Sequential Numbering
• Nutrition & Ingredients
• Other Variable Data

Industries:

• Automotive
• Bottling
• Cannabis
• Chemical
• End of Line Warehousing
• Food and Beverage
• Manufacturing
• Pharmaceutical
• Health and Beauty

Included Features

• Heavy Duty Industrial Design
• 12 Inch Label Storage Spool Standard
• Swing Away Tamp Assemble
• User-Friendly Operating Software
• Batch Counter
• Job Storage
• Printer Status Outputs
• Left and Right-Hand Designs
• 15 Auxiliary I/O Points (Factory Programmable)
• Hand Held User Interface

Optional Features

• Dual Trigger Inputs
• Encoder Port / Conveyor Interface
• Ethernet Interface (Factory Programmable)
• Optional Width of 6.5” x 8.5”
• Power Unwind Label Storage Spool
• Serial Port Communication
• Serial Port Communication
• Smart Tamp
• Tandem Labelers / Zero Down Time
• Touch Screen Interface
• Variety of print engines, left-hand models, alarm, upgrade for longer labels, power unwind for larger spools.”
