Automatic Apply

The hybrid servo drive label applicator designed for continuous, reliable operation in demanding environments.

Product Details

The LabelMill LM4012 is a servo-driven automatic label applicator designed for high-speed, precise labeling, reaching up to 1,400 linear inches per minute with ±1/32 inch accuracy. It handles label sizes from 1/2 inch to 6.5 inches wide and 12 inches long, compatible with various product types like bags, bottles, and boxes. With a durable DC drive motor, user-friendly software, and optional modules for tamp, blow-on, and corner wrap, it’s ideal for industries such as food, beverage, and pharmaceuticals.

• for preprinted labels

Benefits

The LabelMill LM4012 stands out for its ability to deliver both speed and precision, making it a valuable asset for high-volume operations. It handles a wide range of product types and label sizes, offering flexibility to adapt to changing production demands. With its robust construction, intuitive software, and customizable features, the LM4012 streamlines labeling processes, helping businesses maximize efficiency while maintaining top-notch accuracy.

Specs

Labeling Speed/Rate: 1400 linear inches of web per minute standard
Drive System: Heavy duty 1/8 hp DC drive motor
Label Placement: Label placement up to +/- 1/32” when labels are produced to specifications and product handling is controlled
Electrical: 115 VAC/60Hz – 6 amps
Label Roll Capacity: 12” maximum outside diameter wound on a 3” I.D. core. Die-cut waste removed with minimum of 1/8” separations between labels in running direction
Air Requirements: 80 psi/3 cfm when equipped with tamp, flag, blow, swing, or corner wrap
Label Size: Minimum 1/2” wide x 1/2” long, Maximum 61/2” wide x 12” long (optional sizes available)
Environment: Operating 50-95° F (10-35° C), 15-85% RH, non-condensing
General Size: 25”W x 22”D x 21”H
Weight: 60 lbs. with u-arm
Product Sensors: Photoelectric or dry contact (mechanical limit switch)

Use Cases

• Mid to high-volume product applications
• Apply preprinted labels to conveyed or robotically presented

Applications

• Bags and Pouches
• Shipping and Packaging Products
• Pallets
• Bottles and Tubes
• Drum Labeling
• Boxes and Cartons
• Containers
• Flag Labeling

Industries

• Automotive
• Bottling
• Cannabis
• Chemical
• End of Line Warehousing
• Food and Beverage
• Manufacturing
• Pharmaceutical
• Health and Beauty

Included Features
