LM5000 Conveyor Labeling System

LM5000 Conveyor Labeling System

The LM5000 is a fully automated, in-line, turn-key conveyor labeling system. Systems can be configured for single or dual panel labeling as well as wrap labeling at high speeds.

Request Pricing
Questions? We can help.
Contact a Packaging Specialist for product & pricing information.
888-880-0852

LM5000 Conveyor Labeling System

Label Applicator Conveyor Systems

Fully automated, in-line, turn-key conveyor labeling system. Systems can be configured for single or dual panel labeling as well as wrap labeling at high speeds, is a sophisticated solution for product labeling

Product Details

The LabelMill LM5000 is a complete turnkey conveyor industrial labeling system with a wide range of label applicator options. This versatile system can operate as a standalone unit or seamlessly integrate into existing production lines for enhanced automation. The LabelMill Label Applicator systems offer flexibility and reliable performance through a wide variety of application methods, including Tamp, Synchronous Feed, Corner Wrap, Adjacent Panel, and more – Capable of labeling up to 150+ products per minute.

Benefits:

The LM5000 offers fast, precise labeling with the flexibility to handle a wide range of product shapes and sizes, making it ideal for high-volume, multi-product production lines. Its modular design allows for easy customization and seamless integration into existing systems, while the durable build ensures long-term reliability with minimal maintenance. Backed by LabelMill’s decades of industry experience and responsive support, the LM5000 is a smart investment for improving productivity and consistency.

Specs

Labeling Speed/Rate: Up to 200 per minute
Material Handling Conveyor: Adjustable height 6.0” x 72” plastic belt conveyor, Maximum belt speed of 1200” / minute, Heavy duty variable speed DC drive.
Wrap Station: 6” x 24” foam wrap belt module
Product Spacing Station: 8” diameter wheel type product separator module, Centrally mounted control panel, Heavy duty aluminum and powder coated steel construction
Label Roll Capacity: 12” maximum outside diameter wound on a 3” I.D. core, Die-cut waste removed with minimum of 1⁄8” separations between labels in running direction
Air Requirements: 80 psi/3cfm when equipped with tamp, blow, swing, or corner wrap
Label Size: Minimum 1⁄2” wide x 1⁄2” long, Maximum 61⁄2” wide x 12” long (optional sizes available)
Environment: Operating 50-95° F (10-35° C), 15-85% RH, non-condensing

Use Cases

  • Mid to high volume product applications
  • Apply Preprinted or Print & apply labels to conveyed products (Dependent on Label Applicator)

Print & Apply:

  • Barcodes
  • Expiration & Best By Dates
  • Sequential Numbering
  • Nutrition & Ingredients
  • Other Variable Data

Industries:

  • Automotive
  • Bottling
  • Cannabis
  • Chemical
  • Food and Beverage
  • Manufacturing
  • Pharmaceutical
  • Health and Beauty

Included Features

  • Product speeds Up To 200 / Minute
  • Label Speeds up to 2400 Inches a Minute
  • Labeler Close Loop Servo Drive System
  • Seamless LabelMill Label Applicator Integration
  • Touch Screen User Interface
  • 8” Diameter Product Spacer Wheel
  • Servo Drive Motors
  • Heavy Duty Industrial Design

Optional Features

  • System Status Light Tower
  • Loose Loop Interface to Thermal Printer or Color Ink-Jet
  • Optional Width of 8.5” and 10.5”
  • Smart Tamp
  • Custom Product Fixtures
  • Custom Mount Configurations
