LM6000ARS - LM4012 Semi-Automatic Table Top Label Applicator

The LabelMill LM6000ARS AutoRound System with a LabelMill LM4012 hybrid servo drive label applicator to automatically apply pre-printed labels to round products.

Using the LabelMill, LM6000ARS AutoRound System, configured with a LabelMill Label Applicator automatically applies labels to round products, .5” up to 1” OD. The product hopper loads the products into the custom carousel drum to allow the operator to continuously load products to be quickly and precisely labeled. The system automatically senses when a product is not present in the drum to prevent mis-labeling. A centralized touch screen control allows for easy system management and parameter changes.

Specs

Labeling Speed/Rate: 1400 linear inches of web per minute standard
Drive System: Heavy duty 1/8 hp DC drive motor
Label Placement: Label placement up to +/- 1/32” when labels are produced to specifications and product handling is controlled
Electrical: 115 VAC/60Hz – 6 amps
Label Roll Capacity: 12” maximum outside diameter wound on a 3” I.D. core. Die-cut waste removed with minimum of 1/8” separations between labels in running direction
Air Requirements: 80 psi/3 cfm when equipped with tamp, flag, blow, swing, or corner wrap
Label Size: Minimum 1/2” wide x 1/2” long, Maximum 61/2” wide x 12” long (optional sizes available)
Environment: Operating 50-95° F (10-35° C), 15-85% RH, non-condensing
General Size: 25”W x 22”D x 21”H
Weight: 60 lbs. with u-arm
Product Sensors: Photoelectric or dry contact (mechanical limit switch)

Use Cases

  • Mid to high volume product applications
  • Apply preprinted labels to conveyed or robotically presented

Included Features

  • Speeds up to 1400 Inches a Minute
  • Heavy Duty DC Drive
  • Dynamic Motor Control
  • 12 Inch Label Storage Spool Standard
  • Heavy Duty Industrial Design
  • User-Friendly Operating Software
  • Automatic Set-Up
  • Batch Counter
  • Left and Right-Hand Designs
  • Hand Held User Interface

Optional Features

  • Optional Width of 6.5”
  • System Status Light Tower
  • Smart Tamp
  • Loose Loop Interface to Thermal Printer
  • Left or right-hand models, custom systems
