About Hema - CANFL Filler Semi-Solid
Linear Volumetric Filler
The CANFL filler is flexible, precise and well-suited to the challenges of filling complex products. The robustness of the CANFL filler has earned its reputation for value to producers in the meat and fish canning industry. This filler design uses volumetric filling technology, with pistons that are mechanically controlled by a synchronized camshaft.
The CANFL filler is characterized by high-level consistency and precision, guaranteed by the mechanically-controlled cams (repetitive motion).
Filling with Expertise
- Speed: 1,800 to 24,000 containers per hour
- Filling: 1 or 2 heads
- Filling Technology: Volumetric
- Volume: From 100 ml to 2 liters
- Containers: Metal cans, glass or plastic
- Products: corned beef, pâtés, foie gras, luncheon meat, pet food, goulash, tushonka, fish eggs, caviar, fish flakes, cod liver, etc.
CANFL Can Filler Features & Benefits
Versatility: The CANFL filler can handle a wide variety of textures: thick or pasty, homogenous or with pieces (measuring up to 60x40x40mm).
Product integrity: The product integrity stays intact. The desired texture is retained and is not damaged in any way. The proportions of pieces to liquid are taken into account, and there is no product separation.
Optimal efficiency: mechanically designed, the filler guarantees an output level of around 98%.
Product Details
Engineered for Performance
- Speed up to 400 cans per minute
- Different formats : round, rectangular or trapezoidal, with or without slope
- Running different materials : metal, glass or plastic
- Simplified mechanical design for vertical startup
High Accuracy Dosing & Integrity of your products
- Filling cornet with ball and circular cutting knife for hard pate or pieces
- Rotary knife for a perfect product cutting in case of meat with nerves as an alternative (round cans only)
- The “no can-no fill” concept limits losses and guarantees machine cleanliness
- The design of our filling valve guarantees optimal filling accuracy
Unmatched Robustness & Accessibility
- The entire mechanical part of the machine in the oil tank requires no lubrication (guaranteeing long equipment life)
- Safety guards with sliding doors (single head version) for easy access and cleaning, in compliance with EC standards
- A walkway gives access to the product feeding hopper for maintenance or cleaning
- Conveyor transfer: lifting platform in case of bottom filling system
Production Flexibility
- Easy to use filler that requires minimal adjustments to set up
- Adjustment to the height of the frame and the filling volume is motorized
- Production is managed from a tactile operating panel and different parameters are pre-programmed, depending on the recipes being filled
Technical Data
Output: up to 24,000 cans/hour
Number of filler : 1 or 2
Dosed Product Range: 100 - 2,000 ml
Containers: Metal cans, glass or plastic
Compliant with CE regulations
Options
Additional equipment will be integrated from selected suppliers who meet the same standards for quality and reliability. Suppliers of your choice can also be integrated, following a technical assessment.
Packaging Styles
