StraPack SQ-800Y Strapping Machine with Brushless DC Motor
SIDE SEAL AUTOMATIC STRAPPING MACHINE
Introducing StraPack’s new line of strapping machine, the SQ-800 with brushless DC motor. The SQ-800 provides better efficiency without compromising the reliability of the legendary RQ-8x.
Standard strapping rate is 55 straps/min, even when tension is applied. The machine is ready to operate in less than 25 seconds, contributing to increased packaging line efficiencies.
The SQ-800 offers different modes of tensioning system which can be selected according to the application requirements. A wide range of tension is available via a digitally controlled tension dial. Tension capability is up to 80kgf or 176lbf (equivalent of 150mm or 6” stroke). Unlike many other machines in the market, tension does not compromise the cycle speed.
StraPack SQ-800Y Features
- Wide Adaptability to Fully-Automated Packaging Line
- The machine fits any existing or proposed conveyor system, adapts to any conveyor height and requires no special equipment.
- Several options are available to make it easy to integrate the SQ-800Y into a conveyor system.
- Larger arch sizes offer a wide range of applications, particularly for large and heavy packages.
- Strapping Speed
- Standard strapping rate is 50 straps/min, even when tension is applied. The machine is ready to operate in less than 25 seconds, contributing to increased packaging line efficiencies.
- Operation Type:
- Automatic
